| Model | KKC-430 | KKC-530 |
|---|---|---|
| Core Box Size (L x H x W) | 450 x 300 x 250 mm | 500 x 300 x 250 mm |
| Max. Core Size (L x H x W) | 370 x 280 x 200 mm | 420 x 280 x 200 mm |
| Operation Mode | Manual/Single Cycle/Auto Cycle | |
| Production Speed | 40 ~ 70 seconds/cycle, depends on size and shape of products | |
| Heating Type | LPG or Electrical | |
| Max. Blowing Capacity | 10-20 kgs | 15-25 kgs |
| Sand Storage Capacity | 200-300 kgs | |
| Operation Pressure | 5-6 kgs/cm² | |
| Sand Blowing Pressure | 1-4 kgs/cm² | |
| Weight | 2300 kgs | 2400 kgs |
| Dimension | 2010 x 3340 x 2850 mm | 2010 x 3340 x 2850 mm |
